Fuses
40A Ignition Switch, PDM (Power Distribution Modules)
3elay Box (IG 2 3elay), Start 3elay
40A Cooling Fan 1 3elay, Sub junction block (Cooling Fan 2
3elay)
40A Instrument Panel Junction Block (Fuse - DOO3 LOCK,
TU3N LAMP, Tail Lamp 3elay)
40A Ignition Switch, PDM 3elay Box (IG 1 3elay, ACC 3elay)
40A Instrument Panel Junction Block (Power Outlet 3elay)
10A Air Conditioner 3elay
20A PCM (Power train Control Module)
20A Head Lamp LO 3elay
20A Head Lamp HI 3elay
20A Fuel Pump 3elay
1A Burglar Alarm Horn 3elay, Horn 3elay
1A ECM (Engine Control Module)/PCM (Power train Control
Module)
10A Battery Sensor
30A Main 3elay
SZmbol Fuse rating Circuit Protected
