Kidde Fire Systems ECS

Maintenance
October 2014 5-8 06-236115-001
Figure 5-2. Calibration Chart 125lb Cylinder
Figure 5-3. Calibration Chart for Old 200lb Cylinder
0.0
5.0
10.0
15.0
20.0
25.0
50 75 100 125
HFC-227ea Weight (lb.)
Flexible Tape Reading (inches)
130°F
100°F
70°F
30°F
12.0
14.0
16.0
18.0
20.0
22.0
24.0
26.0
28.0
30.0
125 150
175
200
HFC-227ea Weight (lb.)
Flexible Tape Reading (inches)
40°F
70°F
100°F
130°F
