OPTION
INPUT/OUTPUT TERMINALS
The following optional terminals are required to connect a remote controller and an External
monitor.
This is to indicate the settings for the interface setups.
Note that the connection cables between the KDS-5000BB and the external units to be
connected are not supplied as standard.
P. No.
NAMES of TERMINALS
TERMINAL CONNECTIONS
OP-360
VGA OUTPUT
(TERMINAL for
EXTERNAL MONITOR)
No1: RED OUTPUT
No2: GREEN OUTPUT
No3: BLUE OUTPUT
No5: GND
No6: RED GND
No7: GREEN GND
No8: BLUE GND
No10: GND
No13: H-SYNC
No14: V-SYNC
OTHER Nos: NC
STANDARD
SUPPLY
ALARM
(TERMINAL for
EXTERNAL BUZZER)
No1: ALARM
No2: ALARM
*not used currently
*normally open contact
STANDARD
SUPPLY
TRIG - OUT
(TERMINAL for
TRIGGER OUTPUT)
No1: TRIGGER
OUTPUT+
No2: SHIELD
No3: TRIGER OUTPUT-
STANDARD
SUPPLY
NAV - IN
(TERMINAL for
NAVIGATOR)
No1: SIGNAL INPUT+
No2: SIGNAL INPUT-
No3: SHIELD
No4: SIGNAL OUTPUT+
No5: SIGNAL OUTPUT-
STANDARD
SUPPLY
NMEA - OUT
(TERMINAL for
NAVIGATOR or
Something else)
No1: SIGNAL INPUT+
No2: SIGNAL INPUT-
No3: SHIELD
No4: SIGNAL OUTPUT+
No5: SIGNAL OUTPUT-
No6: NC
STANDARD
SUPPLY
SERIAL - IF
(TERMINAL for
EXTERNAL SOUNDER)
No1: SIGNAL INPUT+
No2: SIGNAL INPUT-
No3: SHIELD
No4: SIGNAL OUTPUT+
No5: SIGNAL OUTPUT-
No6: NC
No7: NC
STANDARD
SUPPLY
TRIG - IN
(TERMINAL for
TRIGGER INPUT)
No1: TRIGGER INPUT
No2: NC
No3: NC
No4: NC
No5: GND
No6: NC
No7: NC
No8: SHIELD
* Note that nothing should be connected to the above NC.
A navigator can be connected to NMEA-OUT terminal (No.1 and No.2), but the data of
NAV-IN terminal will prior to NMEA-OUT terminal (No.1 and No.2).
