- 55 -
FUNCTION SETTINGS
5. TX POWER
The output power of the ultra sound wave from the transmitter can be set.
Use the Cursor Shift key ( or ) to select “TX POWER”.
Use the Cursor Shift key ( or ) to change the setting.
TX POWER D Use the Cursor Shift key ( or ) to change.
[A, B, C, D]
D is the maximum level and A is the minimum level.
6. RX GAIN REDUCTION
Reduction of RX gain to weaken too strong reaction in the shallow water can be set.
Use the Cursor Shift key ( or ) to select “RX GAIN REDUTION”.
Use the Cursor Shift key ( or ) to change the setting.
RX GAIN RD. OFF Use the Cursor Shift key ( or ) to change.
[ON, OFF]
ON: reduces the RX gain.
OFF: no change.
