Koden KDS-5000BB - Far Gain Knob; Gain Knob

- 86 -
KNOBS
GAIN KNOB
Rotating this knob clockwise can adjust or increase the
sensitivity of the sonar display.
The gain value can be set via “MENU 2 – GAIN UP”. Refer to page 52
FAR GAIN KNOB
Rotating this knob clockwise increases sensitivity of the sonar for the
last half of the displayed range and adjusts the TVG curve.
Refer to page 53
