Koden KDS-5000BB - Filter; Sub Bottom-Scan; Cursor Direction; Cursor Position

- 67 -
FUNCTION SETTINGS
12. FILTER
The image on the sonar can be enhanced by this function.
Use the Cursor Shift key ( or ) to select “FILTER”.
Use the Cursor Shift key ( or ) to change the setting.
FILTER 1 Use the Cursor Shift key ( or ) to change.
[OFF, 1, 2]
OFF: inactivates filter function.
1: enhances the image on the sonar.
2: enhances further the image on the sonar.
13. SUB BOTTOM-SCAN
Select the SUB BOTTOM-SCAN MODE. Refer to page 61
Use the Cursor Shift key ( or ) to select “SUB BOTTOM-SCAN”.
Use the Cursor Shift key ( or ) to change the setting.
SUB BOTTOM SCAN AUTO Use the Cursor Shift key ( or ) to change.
[AUTO, MANUAL]
AUTO: Sonar Mode changes into BOTTOM-SCAN MODE automatically .
MANUAL: Sonar Mode changes into BOTTOM-SCAN MODE display manually.
14. CURSOR DIRECTION
Select the display way of the CUSOR DIRECTION when an External Navigator connected.
Use the Cursor Shift key ( or ) to select “CURSOR DIRECTION”.
Use the Cursor Shift key ( or ) to change the setting.
CURSOR DIRECTION R-DIRECTION Use the Cursor Shift key ( or ) to change.
[R-DIRECTION, A-DIRECTION]
R-DIRECTION (RELATIVE DIRECTION): corresponds to the ship’s heading direction
T-DIRECTION (TRUE DIRECTION): corresponds to the compass direction
15. CURSOR POSITION
Select the display way of CUSOR POSITION when an External Navigator connected.
Use the Cursor Shift key ( or ) to select “CURSOR POSITION”.
Use the Cursor Shift key ( or ) to change the setting.
CURSOR POSITION DISTANCE Use the Cursor Shift key ( or ) to change.
[DISTANCE, LAT/LONG]
DISTANCE: displays the distance of the cursor position
LAT/LONG: displays the cursor position in latitude/longtude.
