Koden KDS-5000BB - Specifications

- 102 -
ADDITIONS
SPECIFICATIONS
Sonar mode
Bottom scan mode
Scanning range (m) 20 40 60 80 100 120 160 180 200 240 400
Scanning time (sec.) 5º step 5.7 7.6 9.5 11.4 13.3 15.3 19.1 21.0 23.0 26.8 42.2
Scanning time (sec.) 10º step 4.1 5.0 6.0 7.0 8.0 8.9 10.8 11.8 12.7 14.7 22.3
Scanning time (sec.) 15º step 3.5 4.1 4.8 5.4 6.1 6.7 8.0 8.6 9.3 10.6 15.7
Scanning time (sec.) 20º step 3.2 3.7 4.2 4.6 5.1 5.6 6.6 7.1 7.5 8.5 12.3
Processor unit
Hull unit
Processor unit
Hull unit
Power consumption
70 W or less (24 VDC)
70 W or less (24 VDC)
Operating temperature
-15 °C to + 55 °C
Water protection
-
External Output
External buzzer, Trigger output, NMEA output, XGA output, Audio output
USB terminal (memory for setting values)
NMEA ports
Total１: input / output
Power supply
21.6 to 31.2 VDC
21.6 to 31.2 VDC
Functions
Operation mode (3 modes), Off-center (4 changes), Train correct, Power rejection
Gain adjust, Temperature adjust, Pulse width control, TVG change, Target lock
Color change (4 types + 2 types of color palette settings), Dynamic range
Interference rejection, Color rejection, Filter (OFF/1/2), Gain control, Far gain control
External trigger synchronization, Trigger signal output
Hoist sensor lamp, Audio (optional speaker required), Stabilizer (up to 25°controllable)
Transducer unit automatic retract (Navigator connect required), Full-screen gain control
Language
English, Japanese
External Input
Trigger input, Navigator input, External sounder input, Remote controller input
Off-Center
Fore, Back, Left, Right
Target lock
Reverse, Horizontal, Horizontal + Vertical, Marker + Horizontal
Presentation colors
8/16 colors
360º Scanning time
(extracts)
Bearing center
every 5°step selectable
Presentation modes
Sonar mode + Data display, Off-center mode + Data display
Off-center on the whole screen, Bottom scan mode + Data display,Sounder Mode + Data
display
Data display
Secter center angle, Tilt angle, Tilt angle indicator, Ring marker, Cross Cursor
Compass (option), Navigation (option)
Basic ranges
8 ranges freely set
Range units
m, ft, fm, br
Scanning
sector
angles
5°step: 5°, 25°, 45°, 85°, 125°, 165°, 205°, 360°
10°step: 10°, 30°, 50°, 90°, 130°, 170°, 210°,360°
15°step: 15°,45°,75°,105°,135°,165°,225°,360°
20°step: 20°,60°,100°,140°,180°,220°,260°,360°
3°step: 3°, 27°, 45°, 63°, 93°, 117°, 147°, 177°
5°step: 5°, 25°, 45°, 65°, 95°, 115°, 145°, 175°
TD stroke
180 to 380 mm (Recommended value 180 mm)
Display size and type
Any monitor with XGA resolution (Owner supplied)
Display resolution
1024 x 768 （XGA）
Output frequency
180kHz
Tilt angle
+5° to -90° (1°step)
Beam angle
10°
Output power (RMS)
1.5kW
Processor unit
Operation unit
Hull unit
DPU-510
DOU-520
DHU-530
Item
Content
Model
KDS-5000BB
