FACTORY SETTINGS
FACTORY SETTINGS
The factory settings are shown in the below box. Select the desired settings before use.
FUNCTION SETTINGS
FACTORY SETTINGS (shown in AA)
Referring page
FUNCTION SET
MENU 2
GAIN UP
OFF  +10dB  +20dB  +30dB  +40dB  +50dB
PAGE 51-56
TVG CURVE
OFF  10LOG  20LOG  30LOG  40LOG
DYNAMIC RANGE
1 dB  2 dB  3 dB
PULSE WIDTH
X1  X1.5  x2
TX POWER
A  B  C  D
RX GAIN RED.
OFF  ON
RX BANDWIDTH
S. WIDE  WIDE  STANDARD
NARROW  S. NARROW
FULL –SCREEN GAIN SET
OFF  ON
REJECTION
PAGE 57
INTERFERENCE REJ
OFF  ON
DISP ITEM SEL
PAGE 58-67
SUB-DISPLAY
NO SUB-DISP.  INFO  HISTORICAL  +PRESS
+A-SCOPE  BOTTOM  TRACK  EXTSOUNDER
STEP (SONAR)
5° 10°  15° 20°
STEP (BOTTOM-SCAN)
3°  5°
OFF-CENTER POS.
FORE  BACK  LEFT  RIGHT
SCALE DOTS
OFF  ON
COMPASS DISP.
OFF  ON
HEADING DISP.
OFF  ON
TRACK DISP.
OFF  ON
TRACK SUB RANGE
50m (10-500 depth unit)
TRACK MEM. INTERVAL
5 SEC  10 SEC  30 SEC  60 SEC
PRESS RATE
1/2  1/4  1/8  1/16
FILTER
OFF  1  2
SUB BOTTOM-SCAN
AUTO  MANUAL
CURSOR DIRECTION
R-DIRECTION  T-DIRECTION
CURSOR POSITION
DISTANCE  LAT/LONG
OTHERS
PAGE 68-75
AUDIO LEVEL
0 (0-31)
TARGET LOCK
MODE0  MODE1  MODE2  MODE3
TRIGGER SIGNAL
INTERNAL  EXTERNAL
DEPTH UNIT
m  ft  fm  br
TEMP. UNIT
°C  °F
TEMP. ADJUST
+0.0°C ( -9.9° ~ +9.9°)
SPEED UNIT
kt  km/h
AUTO RETRACT
OFF  1kt (1~27km/h or 1kt ~15kt)
TRAIN CORRECT
0° (0°- 355°)
PANEL BRIGHTNESS
15 (0 - 15)
POWER S. FREQUENCY
120k  125k  130k
TD AUTO DOWN
OFF  ON
OPE.MODE MEMORY
OFF  ON
