KNOBS
SECTROR KNOB
The horizontal training angle can be changed when SONAR MODE selected.
The vertical training angle can be changed when BOTTOM-SCAN MODE selected.
[SONAR MODE] [BOTTOM-SCAN MODE]
Displays the selected sector angle
Changes this angle
Changes this angle.
Clockwise rotation ( ) increases the sector width and counterclockwise rotation ( )
decreases it. The desired step can be selected via “ ”. Refer to page 63
SONAR MODE
5°
STEP
5°
25°
45°
85°
125°
165°
205°
360°
10°
STEP
10°
30°
50°
90°
130°
170°
210°
360°
15°
STEP
15°
45°
75°
105°
135°
165°
225°
360°
BOTTOM-SCAN MODE
3°
STEP
3°
27°
45°
63°
93°
117°
147°
177°
5°
STEP
5°
25°
45°
65°
95°
115°
145°
175°
