COMPONENTS
HULL UNIT (DHU-530)
Name of item
Hull unit
Shaft guides
Gum packing
for flange
Crank handle
Damper
Type
DHU-5301
ESR-1510
ESR-1512
OB-63
34924D
Q’TY
1
3
1
1
1
Name of item
TD shaft
Fixing collar
Shift cap
Bolt set
Type
ESR-1504 (1411mm)
ESR-160 32679C-2 (1681mm)
ESR-160 32679C-3 (1981mm)
32681D
34378D
SUS-M16x65-
Assy
Q’TY
1
2
1 set
1 set
Name of item
Cap bolt
Grease
Anp base
Binding band
HEX. ROD
wrench
Type
SUS-M4x10
G-100
ANP-1
AB-100-1000
-
Q’TY
4
1
2
2
1 each
Name of item
Transducer
unit
Bath cork
HEX. ROD
wrench
Type
ESR-1603
-
-
Q’TY
1
1
1 each
1.5mm
2.5mm
3mm
3mm
5mm
