8.4 Components of a servo system
42 SERVOSTAR
®
640/670 Instructions Manual
Electrical Installation
12/2010 Kollmorgen
24V-power
supply
Fuses
Drive contactor
Terminals
Motor
PC
Control / PLC
Mains choke
Fuses
Mains filter
Brake resistor
Cables drawn bold are shielded. Electrical ground is
drawn with dash-dotted lines. The required accesso
-
ries are described in our accessories manual.
restart lock -AS-
SERVOSTAR 640/670
