9.3.1.3 Minimum Wiring for Drive Test
This wiring does not fulfill any requirements to safety or functionality of your
application, it just shows the required wiring for drive testing without load.
SERVOSTAR
®
640/670 Instructions Manual 81
Kollmorgen
12/2010 Setup
Motor-Feedback
Motor-Power
Motor
Power ON
24V DC
+
-
Enable
Power
2
3
18
3
4
5
X4
X3
24V ON
15
Choke Filter
Brake Res.
RES
ENC
PC
CAN
