MSP 3500 Printer
4
4-1
4 MSP 3500 Printer
4.1 Parts of the Printer
1 Top Cover Release Lever: Use to open the Top Cover.
2 Output Tray Extension: When printing in paper B4 or larger, fold open.
3 Power Indicator: Light indicates when the Printer is turned ON.
4 Power Switch: Use to turn the Printer ON and OFF.
5 Paper Guides: Slide the guides to secure the paper stack.
6 Paper Feeding Tray: Capable of holding up to 200 sheets of standard-size
paper ranging from 8-1/2"
× 11" (A4) to 11" × 17" (A3)
paper.
7 Paper Cassette: Capable of holding up to 500 sheets of standard-size
paper ranging from 5-1/2"
× 8-1/2" (B5) to 11" × 17"
(A3) paper.
