CP3003-SA CP-RIO3-04 Rear I/O
ID 1052-6929, Rev. 3.0 Page C - 11
D R A F T — F O R I N T E R N A L U S E O N L Y
C.5.7 Rear I/O Interface on CompactPCI Connector rJ2
The CP-RIO3-04 rear I/O module conducts a wide range of I/O signals through the rear I/O con-
nector rJ2.
Figure C-11: Rear I/O CompactPCI Connector rJ2
Warning!
To support the rear I/O feature, a 3U CompactPCI backplane with rear I/O
support is required. Do not plug a rear I/O configured board in a backplane
without rear I/O support. Failure to comply with the above will result in damage
to your board.
Note:
Pinrow F: GND
Pinrow Z: NC
22
1
ABCDE
Z F
rJ2
