SEQ P0–2: Play/REC Control 0–2–8: Control Surface
143
0–2–8: Control Surface
The control surface consists of the four knobs located in the
left side of the front panel and the four switches to their left.
You can use this control surface in a variety of ways, such as
editing the sound, controlling the arpeggiator, or
transmitting MIDI messages to external devices.
This page shows you the current values for each of the
knobs, along with information about what they are
controlling. For instance, you can:
•Use the knobs to modulate sounds and effects
•Use the knobs to transmit MIDI messages
•Use the knobs to control the arpeggiator
CONTROL ASSIGN switches and parameters
You can use Control Assign in the display or the front panel
REALTIME CONTROL, EXTERNAL, ARP switches to
switch the function of the control surface. Since the display
and the front panel switches are linked, changing one will
change the other correspondingly.
In Sequencer mode, you can select one of three different
functions:
Realtime Control: Use the knobs to control the sound or
effects.
External lets you send MIDI messages to external MIDI
devices. Use the Global P1: MIDI– External Mode 1/2 page
to specify the MIDI message that will be transmitted.
ARP: Use the knobs to control the Arpeggiator.
You can freely change back and forth between the different
functions, without losing any of your edits.
Reset controls
The front panel RESET CONTROLS switch lets you return
the desired knobs of the control surface to their saved
values. You can also use this to reset the Arpeggiator
settings.
Resetting a single control
To reset individual knob:
1. Hold down the RESET CONTROLS switch.
2. While holding down RESET CONTROLS, move a
knob, or press one of the control surface buttons.
The knob will be reset to the value stored in the Program.
3. When you’re done, release the RESET CONTROLS
switch.
Resetting a group of controls
1. Use the display’s Control Assign or the front panel
CONTROL ASSIGN switches to access the controllers
you want to reset.
Note: As a safety precaution, you can only reset the
parameters currently displayed on the Control Surface.
If you want to reset filter settings etc., press the CONTROL
ASSIGN REALTIME CONTROL switch to select RealTime
Control A mode.
2. Hold down the RESET CONTROLS switch.
3. While holding down RESET CONTROLS, press the
current CONTROL ASSIGN REALTIME CONTROL
switch again.
All knobs shown in the control surface will be reset to their
default values.
Resetting Arpeggiator parameters
You can also perform the following reset operations for
Arpeggiator:
To reset the knobs of each arpeggiator, hold down the
RESET CONTROLS switch and press the ARP switch. When
you execute this, the arpeggiator will be reset to the values
stored in the combination.
0–2–8a: Track Select, Tempo, RPPR
Track Select [Track 01…16, Master Track]
(Tempo) [040.00…300.00, EXT]
RPPR [Off, On]
Here, you can select the track, specify the tempo that will
control arpeggiator etc., and turn RPPR on/off.
For more information, please see “0–1–1(2)a: Location,
Meter, Tempo, Tempo Mode, Song Select, Track Select, Reso,
RPPR” on page 129.
0–2–8b: Control Assign
Control Assign [Realtime Control, External, ARP]
This selects the items that will be affected by the control
surface. You can also press one of the CONTROL ASSIGN
switches to make this selection.
For details on each selection, please see the explanations that
follow.
