Setup Mode
Controllers
The PC3’s physical controllers include the following:
• The nine sliders (A, B, C, D, E, F, G, H, I) in the Assignable Controllers section
• The two Continuous Control Pedal jacks (CC Pedal 1 and CC Pedal 2)
• The optional Ribbon Controller, which you can define as a one- or three-section controller
• The Pitch Wheel
• The Modulation Wheel (Mod Wheel)
• Keyboard aftertouch, or Mono Pressure (MPress)
• The optional Breath Controller (which is connected to Continuous Controller Pedal 2)
• The two Panel Switches above the Pitch and Mod Wheels and Program Buttons 1-8
• The three Footswitch pedal jacks (1, 2, and 3)
The following tables and illustration provide an overview of the physical controllers and their
parameters.
Continuous Controllers
Physical Controller
Setup Editor
Page
Parameter:Values
Sliders A, B, C, D, E, F, G, H, I SLID, SLID2
Destination: Control Destination List
Scale: -300% to 300%
Add: -128 to 127
Curve: Linear, Compress. Expand
Entry Value: None, 0 to 127
Exit Value: None, 0 to 127
CPedals 1 & 2 / Breath CPEDAL (same as Sliders)
Ribbon RIBBON (same as Sliders)
Pitch Wheel and Mod Wheel WHEEL (same as Sliders)
MPressure PRESS (same as Sliders)
Table 7-3 Continuous Controllers
