7-34
Setup Mode
The Arpeggiator Switch (ARP SW) Page
The Arpeggiator Switch (ARP SW) Page
The PC3 keyboard offers two Panel switches, located above the pitch and mod wheels. The left
switch is the Arp (short for “arpeggiator”) button. By default, the Arp switch functions as the
arpeggiator switch, and toggles on and off the PC3 arpeggiator, but you can assign this switch to
any Controller.
See The Arpeggiator (ARPZON) Page on page 7-38 for information on how to configure the PC3’s
arpeggiator.
The ARP SW page parameters are described in Switch Controllers on page 7-21.
Parameter Range of Values Default
Type Momentary, Toggled Toggled
On Control Control Destination List ArpOn
On Value None, 0 to 127 127
Off Control Control Destination List ArpOff
Off Value None, 0 to 127 0
Entry Value None, Off, On None
Exit Value None, Off, On None
