Song Mode and the Song Editor
Song Mode: The MIXER Page
12-9
Song Mode: The MIXER Page
The MIXER page shows the initial settings for the program number, panning, and volume of
each track (in groups of 8). The bottom part of the screen displays information about the
currently selected track. To change the currently selected track, use the Chan/Layer buttons, or
use the Trk parameter in the lower left-hand corner of the screen. The current track number, as
well as the range of tracks displayed on the page, are displayed in the upper right-hand corner
of the screen.
Remember, all but the bottom line of the MIXER page show the initial settings for the displayed
and current tracks. The bottom line shows the current settings—which may change throughout
the course of the sequence—for the current track. Below is displayed an example MIXER page:
**Uneditable
The
Rec
,
Play
, and
Stop
Soft Buttons
These soft buttons function as described in The Rec, Play, and Stop Soft Buttons on page 12-5.
The
Keep
Soft Button
Pressing the Keep soft button captures the current settings for each track’s program, panning,
and volume as the initial settings. Remember to save if you want these change to be permanent!
Parameter Range of Values Default
Initial Pan 0 to 127 None
Initial Volume 0 to 127 None
Initial Program Program List None
Selected Track (Trk) 1 to 16 1
For Selected Track
(Initial Program)
Program List None
Initial Volume 0 to 127 None
Initial Pan 0 to 127 None
Current Program** Program List
(Current Program)
Current Volume** 0 to 127 127
Current Pan** 0 to 127 64
