Program Mode
The COMMON Page
6-33
You can remap the keymaps of any program, but you probably won’t want to do this. Drum
remapping, say, a piano program (e.g., 1 Standard Grand) will result in very unpiano-like
behavior.
Exclusive Zone Map
The Exclusive Zone Map is another parameter that applies principally to drum programs. When
using a drum program, you may want the closed hi-hat sounds to “cut off” open hi-hat sounds.
Since you can remap the keymaps of drum programs, this parameter remaps “cut off keys”
accordingly.
Like Drum Remap, you can use this parameter on any program, but you probably won’t want to
do this.
The COMMON Page
The COMMON page is reached by pressing the COMMON soft button in the Program Editor.
Here’s where you find 12 frequently-used parameters that affect the entire current program, not
just the current layer.
Notice that when the Monophonic parameter is set to its default value of Off, the four
monophonic parameters do not appear on the page.
Parameter Range of Values Default
Pitch Bend Range Up ± 7200 cents 200
Pitch Bend Range Down ± 7200 cents -200
Monophonic Off, On Off
(Legato Play) Off, On Off
(Portamento) Off, On Off
(Portamento Rate) 1 to 3000 keys per second 70
(Attack Portamento) Off, On On
Globals Off, On Off
Output Gain -96 to 24 decibels 0
Output Pan ± 64 0
Output Pan Mode Fixed, +MIDI +MIDI
Demo Song Demo Song List 0 None
