Effects
Effects Mode
9-5
Effects Mode
Press the Effect mode select button to enter Effects mode. As stated previously, the
configurations in Effect mode apply in every mode except for Setup mode and Song mode—
these modes have their own Effects page (almost identical to those in Effects mode) whose
configurations take precedence over those of Effect mode.
The CHANFX Page
NOTE: In Setup mode and Song mode, this page corresponds in appearance and function to the FX page,
though the FX page works on a per setup/song basis.
Pressing the CHANFX soft button calls up the CHANFX page. This page is where you’ll allocate
effects processing power. See Processor Power Allocation on page 9-2 for a description of reading
and configuring the CHANFX page.
The AUXFX1 and AUXFX2 Pages
NOTE: In Setup mode and Song mode, these pages corresponds in appearance and function to the
AUXFX pages, though they work on a per setup/song basis.
Pressing the AUXFX1 soft button or the AUXFX2 soft button calls up, respectively, the AUXFX1
page or the AUXFX2 page. As stated above, in Effects mode, Setup mode, and Song mode, the
AUXFX1 and AUXFX2 pages provide overrides for Aux Chain selection and other Aux Effects
parameters. See Aux Override on page 9-3 for a description of the Aux overrides.
Each AUXFX page appears as shown below (the page shown below is the AUXFX1 page):
Parameter Range of Values Default
Override No, Yes No
Chain Chain List 0 None
Output auto, Pri., Sec. auto
Mod Override Control Source List None
Send Level [p], -96 to 24 dB [p]
Pre-/Post- Insert [p], pst, pre [p]
