KYMCO MX’er 125 - Service Information

12. FRONT WHEEL/FRONT BRAKE/FRONT
SUSPENSION/STEERING SYSTEM
12
-
2
MX’er SYSTEM
SERVICE INFORMATION
GENERAL INSTRUCTIONS
• Remove the machine frame covers before removing the front wheel. Jack the machine front wheel off
the ground and be careful to prevent the machine from falling down.
• During servicing, keep oil or grease off the brake drum and brake linings.
• Inspect the brake system before riding.
SPECIFICATIONS
Item
Standard (mm)
Service Limit (mm)
Radial

2.0
Axial

2.0
Front brake drum I.D
110
111
Front brake lining thickness
4
1.5
Tie rod leng
th
266.5

Rod
-
end (tie rod) angle
180
º

TORQUE VALUES
Steering stem nut 6.0 8.0kgf-m
Swing arm nut 4.0 5.0kgf-m
Front wheel nut 6.0 8.0kgf-m
Front wheel hub nut 6.0 8.0kgf-m
Front shock absorber upper
mount bolt 3.5 4.5kgf-m
Front shock absorber lower
mount bolt 3.5 4.5kgf-m
Front wheel rim run out
