KYMCO MX’er 125 - Rear Wheel;Swing Arm;Hydraulic Brake

13. REAR WHEEL/SWING ARM/
HYDRAULIC BRAKE
13
-
2
MX’er SYSTEM
SERVICE INFORMATION
GENERAL INSTRUCTIONS
• During servicing, keep oil or grease off the brake drum and brake linings.
• Drain the brake fluid from the hydraulic brake system before disassembly.
• Contaminated brake disk or brake pads reduce stopping power. Clean the contaminated brake disk
with high-performance brake degreaser and replace the brake pads.
• Do not use brake fluid for cleaning.
• Bleed air from the brake system if the brake system is removed or the brake is soft.
• Do not allow any foreign matters entering the brake reservoir when filling the brake reservoir with brake
fluid.
• Brake fluid will damage painted, coated surfaces and plastic parts. When working with brake fluid, use
shop towels to cover and protect painted, rubber and plastic parts. Wipe off any splash of brake fluid
with a clean towel. Do not wipe the motorcycle with a towel contaminated by brake fluid.
• Make sure to use recommended brake fluid. Use of other unspecified brake fluids may cause brake
failure.
• Inspect the brake operation before riding.
SPECIFICATIONS
Item
Standard (mm)
Service Limit (mm)
Radial

2.0
Rear wheel
Axial

2.0
Rear brake drum I.D
130
131
Rear brake lining thickness
4.5
2.0
Item
Standard Limit (mm)
Service Limit (mm)
Brake disk thickness
3.7
3.0
Brake di
sk runout
0.15
0.3
Brake master cylinder I.D.
12.7
12.743
12.75
Brake master cylinder piston O.D.
12.657
12.684
12.64
Brake caliper piston
I
.D.
33.95
33.99
34.05
Brake caliper cylinder
O
.D.
33.88
33.92
33.85
TORQUE VALUES
Rear wheel nut 6.0 8.0kgf-m
Rear shock absorber upper mount bolt 3.5 4.5kgf-m
Rear swing arm axle 6.0 8.0kgf-m
Rear wheel hub nut 6.0 8.0kgf-m
Rear wheel shaft nut 11.0 13.0kgf-m
Brake arm bolt 1.8 2.5kgf-m
Caliper holder bolt 2.4 3.0kgf-m
Brake fluid tube bolt 2.5 3.5kgf-m
Caliper bleed valve 0.4 0.7kgf-m
Master cylinder bolt 1.0 1.4kgf-m
SPECIAL TOOLS
Rim run
out
