KYMCO MX’er 125 - Instrument; Indicator Light

18. ONLY ATV ON ROAD AVAILABLE
18
-
3
MX’er SYSTEM
INSTRUMENT
REMOVAL
Remove the two instrument attaching screws.
Disconnect the instrument.
Remove battery cover on instrument back to
replace battery.
SENSOR WHEEL
If the sensor is lost or wore, the speed will be
not calculated on the instrument.
INDICATOR LIGHT
REMOVAL
Remove the screw and disconnect the cover of
the ignition switch.
Screws
Battery Cover
After replace battery, the instrument will be
reset. (Refer to owner’s manual)
*
Speed Wheel
Screw
