15. IGNITION SYSTEM
15
-
1
MX’er SYSTEM
IGNITION CIRCUIT
Ignition Switch
CDI Unit
/Change Gear Control.
ntrol
A.C. Generator
Pulser Coil
Spark Plug
Ignition
Coil
PULSER COIL
