MX’er SYSTEM
SERVICE INFORMATION
GENERAL INSTRUCTIONS
• Check the ignition system according to the sequence specified in the Troubleshooting.
• The ignition system adopts CDI unit , change gear control and the ignition timing cannot be adjusted.
• If the timing is incorrect, inspect the CDI unit, A.C. generator, change gear control and replace any faulty
parts. Inspect the CDI unit with a CDI tester
• Loose connector and poor wire connection are the main causes of faulty ignition system. Check each
connector before operation.
• Use of spark plug with improper heat range is the main cause of poor engine performance.
• The inspections in this section are focused on maximum voltage. The inspection of ignition coil resistance
is also described in this section.
• Inspect the ignition switch according to the continuity table specified in page
17-5.
• Inspect the spark plug referring to Section 3.
SPECIFICATIONS
Item Standard
Standard type CR8E
Spark plug Hot type
Cold type
Spark plug gap 0.6 0.7mm
Ignition timing
“F” mark
Full advance
15ºBTDC/1,700±100rpm
Primary coil 0.2 0.3Ω
Ignition coil resistance (20 ) Secondary with plug cap 3.2 4.8KΩ
coil
plug cap 4.2 5.2KΩ
Pulser coil resistance (20 ) 50 60Ω
Exciter coil resistance (20 ) 100 120Ω
Ignition coil primary side max. voltage 12V min.
Pulser coil max. voltage 2.1V min.
TESTING INSTRUMENT
Kowa Electric Tester
or commercially available electric tester with resistance over 10MΩ/CDV
TROUBLESHOOTING
