7. CYLINDER HEAD/VALVES
7
-
7
MX’er SYSTEM
Remove the carburetor.
Remove the exhaust muffler.
Remove the carburetor intake manifold.
Remove the two cylinder head bolts.
Remove the cylinder head.
Remove the dowel pins and cylinder head
gasket.
Remove the cam chain guide.
Remove all gasket material from the cylinder
mating surface.
CYLINDER HEAD
DISASSEMBLY
Cylinder Head
D
owel Pins
Intake Manifold
Cam Chain Guide
Cylinder Head Gasket
Bolts
•
Avoid damaging the cylinder mating
surface.
• Be careful not to drop any gasket material
into the engine.
*
Bolts
