MX’er SYSTEM
SERVICE INFORMATION
GENERAL
! WARNING
•Before running the engine, make sure that the working area is well-ventilated. Never run the engine in
a closed area. The exhaust contains poisonous carbon monoxide gas which may cause death to
people.
•Gasoline is extremely flammable and is explosive under some conditions. The working area must be
well-ventilated and do not smoke or allow flames or sparks near the working area or fuel storage
area.
SPECIFICATIONS
ENGINE
Throttle grip free play : 1 4mm
Spark plug gap : 0.6 0.7mm
Spark plug: Standard : NGK: CR8E
Valve clearance : IN: 0.06mm
EX: 0.06mm
Idle speed : 1700±100rpm
Engine oil capacity:
At disassembly : 1.0 liter
At change : 0.9 liter
Gear oil capacity :
At disassembly : 400cc
At change : 200cc
Cylinder compression : 16kg/cm²
Ignition timing : BTDC 15°/1700rpm
CHASSIS
Front brake free play: 10 20mm
Rear brake free play: 10 20mm
TIRE PRESSURE
1 Rider
Front 0.20kgf/cm²
Rear 0.25kgf/cm²
TIRE SIZE:
Front : 20*7-8
Rear : 22*10-8
TORQUE VALUES
Front wheel nut 5.0 6.0kgf-m
Rear wheel nut 5.0 6.0kgf-m
