MX’er SYSTEM
FUEL LINE
Remove the met-in box.
Check the fuel tubes and replace any parts,
which show signs of deterioration, damage or
leakage.
THROTTLE OPERATION
Check the throttle to swing for smooth
movement.
Measure the throttle to swing free play.
Free Play: 1 4mm
Minor adjustment is made with the adjusting nut
at the throttle to swing above.
Slide the rubber cover out and adjust by
loosening the lock nut and turning the adjusting
nut.
AIR CLEANER
AIR CLEANER REPLACEMENT
Remove the rear side covers.
Remove four screws on the air cleaner case
cover and the cover.
Check the element and replace it if it is
excessively dirty or damaged.
