2. FRAME COVERS/EXHAUST MUFFLER
2
-
5
MX’er SYSTEM
HEADLIGHT REMOVAL
Remove the headlight connector wire.
Remove the two bolts on the headlight.
EXHAUST MUFFLER
REMOVAL
Remove the two bolts attaching the exhaust
muffler.
Remove the two exhaust muffler joint lock nuts.
Remove the exhaust muffler joint packing
collar.
When installing, first install the exhaust muffler
packing collar onto the engine and then install
the exhaust muffler.
Torque:
Exhaust muffler lock bolt: 3.2 3.8kgf-m
Exhaust muffler joint lock nut: 0.8 1.2kgf-m
Bolt
s
Joint Lock Nuts
Be sure to install a new exhaust muffler
packing collar.
*
Bolt
s
