KYMCO MX’er 125 - Engine Installation

6. ENGINE REMOVAL/INSTALLATION
6
-
4
MX’er SYSTEM
ENGINE HANGER BRACKET
REMOVE
Remove the two bolts on the left engine hanger
bracket.
Remove the left engine hanger bracket.
Remove the engine.
ENGINE INSTALLATION
Install the engine and tighten the engine
mounting bolts.
Torque: 3.5 4.5kgf-m
Install the removed parts in the reverse order of
removal.
Bolt
Engine Hanger Bracket
Bolts
Route the wires and cables properly.
*
