MX’er SYSTEM
Disconnect the spark plug high-tension wire.
Remove the spark plug cap and disconnect the
ignition coil wire from the set plate.
Remove the rear drive chain gear on the bolts.
Remove the drive chain gear.
Remove the two bolts and two joint lock nuts
attaching the exhaust muffler.
Remove the exhaust muffler.
ENGINE REMOVAL
Remove the engine any connector thing.
Remove the engine back bracket tow bolts.
Remove the engine front bracket bolt.
