MX’er SYSTEM
Remove the front wheel, wheel hub, brake
shoe plate.
Remove the upper and lower bolt, then remove
the shock absorber.
Remove the cotter pin and nut, then remove
tie-rod from steering knuckle.
Remove cotter pin, nut, washer and bolt, then
remove the steering knuckle, covers, collar and
bush from the front arm.
INSPECTION
Check the front arm brackets of the frame.
If bent, cracked or damaged, repair or replace
the frame.
Check the tightening torque of the front arms
securing nuts.
Torque: 4.0 5.0kgf-m
