Install the rubber cover.
Install the brake lever.
Install the brake fluid tube with the bolt and two
sealing washers. Then, install the rearview
mirror.
Fill the brake reservoir with recommended
brake fluid to the upper level.
Bleed air from the hydraulic brake system.
(Refer to 13-17.)
Place the brake master cylinder on the
handlebar and install the master cylinder holder
with the “UP” mark facing up, aligning the tab
on the holder with the hole in the handlebar.
First tighten the upper bolt and then tighten the
lower bolt.
Torque: 1.0 1.4kg-m
BRAKE CALIPER
REMOVAL
Remove the brake caliper, brake pads and pad
spring.
Place a clean container under the brake caliper
and disconnect the brake fluid tube from the
brake caliper.
DISASSEMBLY
