13. REAR WHEEL/SWING ARM/
HYDRAULIC BRAKE
13
-
24
MX’er SYSTEM
Washer
Fl
uid Tube Bolt
Aligning The
Fluid Tube
With Groove
Install the brake caliper onto rear axle hub and
tighten the bolts.
Torque: 2.4 3.0kg-m
