1. GENERAL INFORMATION
1
-
17
MX’er SYSTEM
Sprocket hub/Rear
Axle Hub Collar/Oil
Seal/Bearing
Rear Brake Cam/ Axle
Hub Collar/Oil
Seal/Bearing
Driven Sprocket
Swing arm Thrust
Cover
