3. INSPECTION/ADJUSTMENT
3
-
8
MX’er SYSTEM
Remove the oil dipstick and check the oil level
with the oil dipstick.
If the level is near the lower level, fill to the
upper level with the specified engine oil.
OIL CHANGE
Remove the oil drain plug bolt located on the
bottom of the engine to drain the engine oil
thoroughly.
After the oil has been completely drained,
Install the oil drain plug bolt.
Torque: 2..0 3.0kgf-m
Recommended Oil: SAE30#
FINAL REDUCTION GEAR OIL
Recommended Oil: GEAR OIL SAE90#
GEAR OIL CHANGE
Remove the oil filler bolt.
Removes the oil drains bolt and drain the oil
thoroughly.
Install the oil drain bolt.
Torque: 0.8 1.2kgf-m
Oil
Filler
Bolt
Make sure that the sealing washer is in good
condition.
*
Place the motorcycle on level gr
ound for oil
level check.
*
Oil Dipstick
Oil Filter Screen Cap
Lower Level
Upper Level
oil
drain plug bolt
The engine oil will drain more easily while
the engine is warm.
*
