2LW/2LX-2
1-4-4
Paper
feeder
30 Paper does not arrive at the
PF paper feed sensor 1 within specified
time from start of paper feed (paper feed from paper feeder 1).
C
Paper does not arrive at the
PF paper feed sensor 1 within specified
time
of the PF paper feed sensor 2 turning on (paper feed from paper
feeder 2)
.
C
Paper does not arrive at the
PF paper feed sensor 1 within specified
time
of the PF paper feed sensor 3 turning on (paper feed from paper
feeder 3)
.
C
31 Paper does not pass the
PF paper feed sensor 1 within specified time
of the PF paper feed sensor 1 turning on.
C
32 Paper remains at the
PF paper feed sensor 1 when power is turned
on.
C
40 Paper does not arrive at the
PF paper feed sensor 2 within specified
time from start of paper feed (paper feed from paper feeder 2).
D
Paper does not arrive at the
PF paper feed sensor 2 within specified
time
of the PF paper feed sensor 3 turning on (paper feed from paper
feeder 3)
.
D
41 Paper does not pass the
PF paper feed sensor 2 within specified time
of the PF paper feed sensor 2 turning on.
D
42 Paper remains at the
PF paper feed sensor 2 when power is turned
on.
D
50 Paper does not arrive at the
PF paper feed sensor 3 within specified
time from start of paper feed (paper feed from paper feeder 3).
E
51 Paper does not pass the
PF paper feed sensor 3 within specified time
of the PF paper feed sensor 3 turning on.
E
52 Paper remains at the
PF paper feed sensor 3 when power is turned
on.
E
Document
processor
70 The DP timing sensor does not turn on within specified time during
the first sheet feeding (Retry 5 times).
I
The DP timing sensor does not turn on within specified time during
the second sheet feeding (Retry 5 times).
I
71 The DP timing sensor does not turn off within specified time of the
DP paper feed motor turning on.
I
72 The DP timing sensor turns off within the specified time of period of
the DP paper feed motor turning on.
I
73 During original switchback operation, DP timing sensor does not
turn off within specified time of the DP paper feed motor turning on.
I
74 The DP timing sensor does not turn on within specified time of the
DP timing sensor turning off.
I
78 The top cover is opened during original feeding.
The DP timing sensor turns on when starting the original paper
feed.
I
*: Refer to figure 1-4-2 for paper jam location (see page 1-4-2)
Section Code Conditions
Jam
location
