Kyocera FS-3040MFP

2LW/2LX
1-5-35
5. Remove two screws and then remove
the FAX control PWB.
(See page 1-5-42)
6. Draw the rear unit.
7. Remove six screws.
8. Remove the clamp and then remove
the controller box.
Figure 1-5-55
Screw
Screw
Controller box
Rear unit
Screw
Screw
Screw
Screw
Clamp
