Kyocera FS-3040MFP - Page 239

2LW/2LX
2-3-12
YC8 24 GND - - Ground
Connected to
CCD PWB
25 CCDDATAG I Analog CCD image output signal (G)
26 GND - - Ground
27 CCDDATAB I Analog CCD image output signal (B)
28 GND - - Ground
29 NC - - Not used
30 +12V O DC12V 12 V DC power to CCDPWB
31 +5V1 O 5 V DC 5 V DC power to CCDPWB
32 +5V1 O 5 V DC 5 V DC power to CCDPWB
YC12 1 OUT- O Analog Speaker sound signal (-)
Connected to
speaker
2 OUT+ O Analog Speaker sound signal (+)
YC13 1 POLRDYN O 0/5 V DC PM ready signal
Connected to
engine PWB
2 POLONN I 0/5 V DC PM: On/Off
3 OUTPEN I 0/5 V DC Laser output enable signal
4 PDMASKN I 0/3.3 V DC Horizontal synchronizing signal
5 SBSY I 0/3.3 V DC Serial busy signal
6 SDIR I 0/3.3 V DC Serial communication direction change
signal
7 EGIRN I 0/3.3 V DC Engine interruption signal
8 EGSI O 0/3.3 V DC (pulse) Serial communication data signal input
9 EGSO I 0/3.3 V DC (pulse) Serial communication data signal output
10 SCKN O 0/3.3 V DC (pulse) Serial communication clock signal
11 RESETN I 0/5 V DC Reset signal
YC14 1 +24V5 O 24 V DC 24 V DC power to PM
Connected to
laser scanner
unit
2 GND - - Ground
3 POLONN O 0/5 V DC PM: On/Off
4 POLRDYN I 0/5 V DC PM ready signal
5 POLCLK O 0/5 V DC (pulse) Serial communication clock signal
6 GND - - Ground
7 VDATAN1 O Video data signal (-)
8 VDATAP1 O Video data signal (+)
9 OUTPEN O 0/5 V DC Laser output enable signal
10 SAMPLEN1 O 0/3.3 V DC Sample/hold signal
11 +5V3 5 V DC 5 V DC power to APCPWB
12 NC - - Not used
Connector Pin Signal I/O Voltage Description
