Kyocera FS-3040MFP

2LW/2LX
2-3-13
YC15 1 +24V5 I 24 V DC 24 V DC power from EPWB
Connected to
engine PWB
2 +5V1 I 5 V DC 5 V DC power from EPWB
3 +5V1 I 5 V DC 5 V DC power from EPWB
4 GND - - Ground
5 +5V1 I 5 V DC 5 V DC power from EPWB
6 GND - - Ground
7 GND - - Ground
8 GND - - Ground
9 +24V4 I 24 V DC 24 V DC power from EPWB
YC16 1 +3.3V - 3.3 V DC 3.3 V DC power to PDPWB
Connected to
PD PWB
2 PDN I 0/5 V DC (pulse) Horizontal synchronizing signal
3 GND - - Ground
YC1001 1 +24V1 I 24 V DC 24 V DC power from CPWB-L
Connected to
connect-L
PWB
2 NC - - Not used
3 GND - - Ground
YC1004 1 SCMOT1A O 0/24 V DC (pulse) ISUM drive control signal
Connected to
ISU motor
2 SCMOT2B O 0/24 V DC (pulse) ISUM drive control signal
3 SCMOT1B O 0/24 V DC (pulse) ISUM drive control signal
4 SCMOT2A O 0/24 V DC (pulse) ISUM drive control signal
YC1005 1 +3.3V O 3.3 V DC 3.3 V DC power to DPDPWB
Connected to
DP drive
PWB
2 GND - - Ground
3 TIMSWN I 0/3.3 V DC DPTS: On/Off
4 ORGSWN I 0/3.3 V DC DPOS: On/Off
5 OPSWN I 0/3.3 V DC DPOCS: On/Off
6 DPDETN I 0/3.3 V DC DP set signal
7 RELSOLN O 0/24 V DC DPPRSOL: On (Release)/Off
8 PRESOLN O 0/24 V DC DPPRSOL: On (Press)/Off
9 REVSOL O 0/24 V DC DPSBSOL: On/Off
10 FEEDCL O 0/24 V DC DPPFCL: On/Off
YC1008 1 MOT1A O 0/24 V DC (pulse) DPPFM drive control signal
Connected to
DP drive
PWB
2 MOT2A O 0/24 V DC (pulse) DPPFM drive control signal
3 MOT1B O 0/24 V DC (pulse) DPPFM drive control signal
4 MOT2B O 0/24 V DC (pulse) DPPFM drive control signal
5 +24V6 O 24 V DC 24 V DC power to PDPWB
6 GND - - Ground
Connector Pin Signal I/O Voltage Description
