Illustrated Parts List
3000C Force Feed Loader 7-7
3000 Force Feeder Loader Auger Moldboard
Item
No.
Part Number Qty. Description Remarks
GRP 984935 3000 FFLA Moldboard Assembly
1 700160-28 2 Cylinder, Hydraulic, 3.50 x 10.00 x 1.75 Rod
2 100-6-16-16-8F 2 CSHH, 3/-8-16 x 1.00, GR8, FT Mounts to frame
3 302-10 8 Washer, Lock, 5/8” Mounts to frame
4 300-6 2 Washer, Flat, 3/8” Mounts to frame
5 1010370 2 Assembly, Pin, 3” Mounts to frame
6 1005814 1 Subassembly, Lift Arm, Scoop, Right
7 1005813 1 Subassembly, Lift Arm, Scoop, Left
8 986374 1 Moldboard, Loader, All-Purpose
9 P523295 1 Cutting Edge, Moldboard
10 130220 8 Plow Bolt, 5/8-11 x 2.00
11 200-10-11-5 8 Nut, Hex, 5/8-11, GR5
REF 302-6 2 Washer, Lock, 3/8 Not Shown
To Next Page
