Illustrated Parts List
3000C Force Feed Loader 7-9
3000 Force Feed Loader Tapered Moldboard (1 of 2)
Item
No.
Part Number Qty. Description Remarks
GRP 984935 Assembly, 3000 FFLT Moldboard
1 210060 8 Pin, Clevis, 1.00 x 2.625 w/1.5 HD
2 700160-28 2 Cylinder, Hydraulic, 3.50 x 10.00 x 1.75 Rod
3 750506 1 Weldment, Wear Plate, Loader
4 750505 1 Assembly, Moldboard
5 200-12-10-8 6 Nut, Hex, 3/4-10, GR8
6 302-12 6 Washer, Lock, 3/4”
7 100-12-10-36-8 6 CSHH, 3/4-10 x 2.25, GR8
8 328370 2 Cylinder, Hydraulic, Moldboard Lift
9 981438RSRV 1 Assembly, Lift Arm, Scoop, Right
10 700131 2 Weldment, Conveyor Pivot, Moldboard
11 1010370 2 Assembly, Pin, 3”
12 101-16-8-48-8 4 CSHH, Heavy, 1-8 x 3.00, GR8
13 300-16 4 Washer, Flat
14 204-16-8-8 4 Nut, Lock, Stover, 1-8, GR8
REF 750510SRV 2 Assembly, Stabilizer Bar Not Shown
15 640350 4 Ball Joint, Moldboard Stabilizer
16 981765 2 Tube, Stabilizer
17 750511 1 Wing, Moldboard, Right
18 750508 2 Cutting Edge, Moldboard Side
19 130220 19 Plow Bolt, 5/8-11 x 2.00
20 302-9 19 Washer, Lock, 9/16
21 200-10-11-8 19 Nut, Hex, 5/8-11-8
22 855192 2 Scoop Holder Rod Pin
23 750512 1 Wing, Moldboard, Left
24 750505-1 1 Weldment, Moldboard
(Moldboard assembly is 750505)
25 750506 1 Weldment, Wear Plate, Loader
26 750507 2 Cutting Edge, Feeder, Low
27 750509 1 Cutting Edge, Feeder
28 301-18 1 Washer, Flat, 1-1/8
29 101-16-8-48-8 2 CSHH Heavy 1-8 x 3.00, GR8
30 986511 2 Spacer, Tube, 3.00 OD x 2.00 ID x .50 LG
31 855164 1 Level Rod Mounting Flat Bar
32 855163 1 Level Rod Indicator
33 981438LSRV 1 Assembly, Lift Arm, Scoop, Left
34 855165 1 Scoop Level Mounting Plate
35 105-10-11-20-F 2 Capscrew, Flat Head, 5/8-11 x 1.25
36 100-6-16-12-8F 4 CSHH, 3/8-16 x .75, GR8, FT Item 36 is welded
