Illustrated Parts List
3000C Force Feed Loader 7-15
FFLA Feeder Assembly (2 of 3)
Item
No.
Part Number Qty. Description Remarks
1 1008869 1 Weldment, Chain Guard, Left
2 1008868 1 Weldment, Chain Guard, Right Same hardware as left side
3 202-12-10-5 8 Nut, Hex, Jam, 3/4-10, GR5
4 302-12 8 Washer, Lock, 3/4”
5 100-12-10-72-5 8 CSHH, 3/4-10 X 4.50, GR5
6 W522855SSG 1 Auger (Snow) Left
7 S16103 4 Washer
8 25583 6 Ring, Nozzle
9 130-342 4 Seal, Feeder Shaft
10 855066SRV 2 Sprocket Set, Feeder Drive
11 W522854SSG 1 Auger (Snow), Right
12 854942SRV 2 Keystock, Square .750 x 3.50
13 710221A 1 Shaft, Feeder, Lower
14 101-10-11-88-5 2 CSHH, Heavy, 5/8-11 x 5.50, GR5
15 300-10 4 Washer, Flat, 5/8”
16 302-10 2 Washer, Lock, 5/8”
17 201-10-11-5 2 Nut, Hex, Heavy, 5/8-11, GR5
To Next Page
