Illustrated Parts List
3000C Force Feed Loader 7-17
FFLA Feeder Assembly
Item
No.
Part Number Qty. Description Remarks
1 984902 1 Weldment, Feeder
2 750553SRV 1 Assembly, Paddle Shaft Arm, Right
3 302-20 8 Washer, Lock, 1-1/4
4 200-14-9-8 8 Nut, Hex, 7/8-9, GR8
5 100-12-10-36-8 8 CSHH, 3/4-10 x 2.25, GR8
6 854934 1 Assembly , Feeder Bearing Adjustment
7 710160-28R 1 Bearing, Conveyor Head Pulley
8 300-18 2 Washer, Flat, 1-1/8”
9 981763 1 Assembly, Rear Shaft Paddle Stop
10 854946A 1 Paddle Bearing Plate
11 750549SRV 1 Assembly, Fender Tensioner, Rod & Nut
12 750551SRV 1 Assembly ,Paddle Shaft Arm, Left
13 854937 2 Washer, Flat, 1.062 x 2.50 x .500
14 710182 2 Sprocket, Feeder Drive
15 710150-28 2 Bushing, Taper Lock, 2.500
16 710171A 1 Shaft, Feeder, Upper
17 120120 1 Locking Collar
18 811316 1 Roller, 3.25 x 1.25
19 710183 1 Bushing, Feeder
To Next Page
