Illustrated Parts List
3000C Force Feed Loader 7-19
Conveyor Paddle Assembly (1 of 3)
Item
No.
Part Number Qty. Description Remarks
GRP 855232 Assembly, Conveyor Paddle
1 710100 1 Motor, Hydraulic, Feeder Drive
2 700480 1 Gasket, “B”, 2-Bolt
3 710090-28 1 Torque Hub, Feeder Drive
4 854932 1 Mount, Torque Hub
5 520100 1 Bearing, Insert, 3.00
6 750323 1 Snap Ring, Conveyor Left Bearing
7 210060 4 Clevis Pin
8 750635SRV 2 Assembly, Feeder Support
9 1010371 2 Assembly, Pin, 2.50”
10 854947 1 Rod, Threaded, Feeder Motor
11 984902 1 Weldment, Feeder
12 710171A 1 Shaft, Feeder, Upper
13 302-12 2 Washer, Lock, 3/4”
14 301-12 4 Washer, Flat, 3/4”
15 100-12-10-36-8 2 CSHH, 3/4-10 x 2.25, GR8
16 140610 3 Fitting, Lube, 1/4”-28
17 710230R 1 Chain Assembly, Feeder, Right
18 710230L 1 Chain Assembly, Feeder, Left
19 200-10-11-8 44 Nut, Hex, 5/8-11, GR8
20 710240 11 Blade Paddle
21 130220 44 Plow Bolt, 5/8-11 x 2.00
22 302-9 44 Washer, Lock, 9/16
23 202-20-12-5 4 Nut, Hex, Jam, 1-1/4-12, GR5
24 100-6-16-16-8F 2 CSHH, 3/8-16 x 1.00, GR8, FT
25 302-6 2 Washer, Lock, 3/8
26 300-6 2 Washer, Flat, 3/8
27 80338 4 Pin, Cotter, .188 x 2.00
To Next Page
