7
Illustrated Parts List
3000C Force Feed Loader 7-23
Conveyor Paddle Assembly (3 of 3)
Item
No.
Part Number Qty. Description Remarks
1 984902 1 Weldment, Feeder
2 750553SRV 1 Assembly, Paddle Shaft Arm, Right
3 302-12 12 Washer, Lock, 3/4
4 200-12-10-5 12 Nut, Hex, 3/4-10
5 100-12-10-40-5 12 Capscrew, Hex Head, 3/4-10 x 2.5
6 202-18-12-5 6 Nut, Hex, Jam, 1-1/8-12
7 811316 2 Cam Follower, 3.25 x 1.25-12
8 300-12 4 Washer, Flat, 3/4”
9 301-18 2 Washer, Flat, 1-1/8
10 750552SRV 1 Assembly, Paddle Bearing Adjustment, Right
11 854953 2 Paddle Roller Spacer
12 750551SRV 1 Assembly ,Paddle Shaft Arm, Left
13 750550SRV 1 Assembly, Paddle Bearing
14 710182 2 Sprocket, Feeder Drive
15 710150-28 2 Bushing, Taper Lock, 2.500
16 710171A 1 Shaft, Feeder, Upper
17 120120 1 Locking Collar
18 854934 1 Assembly ,Feeder Bearing Adjustment
19 710160-28R 1 Bearing., Conveyor Head Pulley
20 981763 1 Assembly, Rear Shaft Paddle Stop
21 854946A 1 Paddle Bearing Plate
22 750549SRV 1 Assembly, Fender Tensioner, Rod & Nut
23 854937 2 Washer, Flat, 1.062 x 2.50 x .500
To Next Page
