Illustrated Parts List
3000C Force Feed Loader 7-27
Rear End Assembly
Item
No.
Part Number Qty. Description Remarks
1 1010634 1 Axle, Rear, Fixed
2 750565 2 Tire, Rear
3 1011183 2 Rim, Rear, Loader
4 1011461 1 Motor, Hydraulic, 2-Speed
5 302-12 12 Washer, Lock 3/4”
6 853360 6 U-Bolt, .750, Loader Rear End
7 80375 12 Nut, Flexloc, .750-16, Full
REF 1011185 1 Assembly, Rear, Tire And Wheel, Left Not Shown
REF 1011186 1 Assembly, Rear, Tire And Wheel, Right Not Shown
REF 993000RE 1 Hose Kit, Drive Axle Not Shown
REF 110210-1 2 Mount, Tie Rod End Not Shown
REF 1011461-01 1 O-Ring Motor Seal Not Shown
