Illustrated Parts List
3000C Force Feed Loader 7-31
Item
No.
Part Number Qty. Description Remarks
38 981740-46 1 Needle Bearing
39 981740-47 1 O-Ring
40 981740-48 1 Reduction Bushing
41 981740-49 2 O-Ring
42 981740-50 1 O-Ring
43 981740-51 1 O-Ring
44 981740-52 1 Piston
45 981740-53 1 Retaining Ring
46 981740-54 1 O-Ring
47 981740-55 1 O-Ring
48 981740-56 1 Seal
49 981740-57 1 Grub Bolt
50 981740-58 1 Spring
51 981740-59 1 Detent, Ball
52 981740-60 1 Seal Washer
53 1010634-79 1 Security Switch
54 981740-62 1 Boot
55 981740-75 2 Stud
56 981740-76 2 Spacer
57 1010634-80 1 O-Ring
58 1010634-81 1 Cover
59 981740-65 1 O-Ring
60 981740-77 2 Spring Washer
61 981740-06 1 Change Selector
62 981740-67 1 Coverplate
63 981740-68 1 Retaining Ring
64 1010634-82 1 Cover
65 1010634-83 1 Output Shaft
66 1010634-84 1 Roller Bearing
67 981740-78 2 Nut
Gear Box (2 of 2)
