Illustrated Parts List
3000C Force Feed Loader 7-33
Hub Reduction
Item
No.
Part Number Qty. Description Remarks
1 1010634-24 2 Axle Case
2 1010634-46 2 Ring Gear Support (Kit)
3 1010634-25 40 Bolt
4 1010634-26 2 Half Shaft
5 1010634-27 2 Seal
6 1010634-28 2 Ring
7 1010634-29 2 Seal
8 981740-51 4 O-Ring, Gear Box
9 981740-137 24 Stud, Wheel
10 1010634-30 2 Wheel Hub
11 1010634-31 24 Nut
12 981740-138 2 O-Ring
13 1010634-32 8 Snap Ring
14 1010634-33 8 Planet Gear
15 1010634-34 8 Bearing
16 1010634-35 2 Planet Gear Carrier (Kit)
17 1010634-36 2 Planet Gear Carrier
18 1010634-37 2 Plug
19 981740-147 4 Bolt, Countersunk
20 1010634-38 2 Friction Washer
21 1010634-39 16 Nut
22 1010634-40 16 Stud
23 1010634-41 2 Locking Plate
24 1010634-42 2 Ring Gear Support
25 1010634-43 2 Ring Gear
26 1010634-44 2 Retaining Ring
27 1010634-08 6 Plug, Magnet
28 1010634-45 2 Pinion
