Illustrated Parts List
3000C Force Feed Loader 7-35
Central Housing
Item
No.
Part Number Qty. Description Remarks
1 981740-38 1 Gear Box, Vent
2 981740-130 4 Bolt, Cylinder
3 1010634-02 4 O-Ring, Central Housing
4 1010634-03 2 Cover, Intermediate
5 1010634-04 1 Housing
6 1010634-05 1 Retaining Ring
7 1010634-06 1 Plug
8 1010634-07 1 Plug
9 1010634-08 1 Plug, Magnet
10 981740-102 1 Plug
11 1010634-88 1 Plug
12 981740-60 1 Gear Box, Seal Washer
